Granalladora de cinta de malla metálica de funcionamiento continuo

Mesh Belt Continuous Shot Blasting MachineProduct descriptionQWD series mesh bel

Send Inquiry

Product details

Granalladora continua de cinta de malla metálica

Descripción del producto

La granalladora de cinta de malla metálica de la serie QWD se utiliza principalmente para la limpieza superficial por granallado de piezas fundidas de pared delgada, piezas fundidas frágiles de hierro o aleación de aluminio de pared delgada, cerámicas y otras piezas pequeñas. También puede emplearse para el granallado de piezas mecánicas. Cuenta con las ventajas de buen funcionamiento continuo, alta eficiencia de limpieza, poca deformación y ausencia de hoyos.

Mediante el granallado se eliminan la capa de óxido, la escoria de soldadura y la suciedad de la superficie de la pieza, logrando un brillo metálico uniforme y mejorando la calidad del recubrimiento y el efecto anticorrosivo. Las piezas limpias atraviesan la zona de granallado de forma automática, continua e ininterrumpida, recibiendo el granallado desde múltiples direcciones.


Datos técnicos

Parámetro	WD 800	WD 1000	WD 1800	WD 1500	WD 1250
Anchura máxima de pieza (mm)	800	1000	1800	1500	1250
Altura máxima de pieza (mm)	400	500	500	500	500
Cantidad de turbinas de granallado	4	4	10	10	8
Potencia de cada turbina (kW)	7,5 (11)	7,5 (11)	11 (15)	7,5 (11)	18,5 (22)

Características

Un buen material define un buen producto. También se pueden seleccionar materiales personalizados. Garantizamos la calidad sin escatimar en materiales.
Larga vida útil, operación cómoda, funcionamiento sencillo y alta eficiencia de trabajo.
Disponible en diversas especificaciones, se puede personalizar según las necesidades del cliente.

Ventajas

Cuenta con las ventajas de gran capacidad de limpieza, alta tasa de proyección, bajo nivel sonoro, amplio ángulo de desviación y excelente efecto de limpieza.

Preguntas frecuentes

¿Qué es una granalladora? Una granalladora es una máquina que controla el flujo de pequeñas esferas metálicas, las cuales son proyectadas con fuerza contra una superficie mediante aceleración mecánica.

¿Qué materiales se utilizan para el granallado? Los abrasivos metálicos empleados en el granallado incluyen granalla de acero, perdigones de cobre y gránulos de aluminio. Otros métodos de granallado utilizan arena de sílice, esferas de vidrio, materiales sintéticos como el bicarbonato de sodio e incluso materiales agrícolas como granos triturados.

¿El granallado elimina el óxido? El granallado es un proceso de abrasión de la superficie de una pieza metálica para eliminar óxido, suciedad y otros contaminantes solidificados, mediante el lanzamiento a alta velocidad de pequeñas partículas de acero inoxidable similares a perdigones. Permite eliminar rebabas, dar forma y texturizar las superficies.
