Rotary Table Shot Blasting Machine For Cleaning Gears and coupling parts

Rotary Table Shot Blasting Machine Description

The main component of the satellite turntable shot blasting machine is the switching mechanism, which moves the workpiece in defined steps in the spray chamber. The best application of this machine is the processing of rotationally symmetrical workpieces. But Knnjoo also provides satellite turntable shot blasting machines for processing motor sets and other asymmetrical workpieces.
A key advantage of this machine is that it can load/unload workpieces while processing other workpieces.
According to workpiece size, application and sandblasting process, the turntable can be designed from 3 to 36 satellites.

Technical datas

process
Generally, the workpiece conveying system of a satellite turntable shot blasting machine (KDT sandblasting machine) includes a precision indexing turntable and several individually driven satellites. The turntable is divided into the following three areas:

1) Loading area

2) The entrance and exit shot the curtain to avoid shooting escape, and

3) Shot blasting area.

Symmetrical workpieces can be loaded and unloaded manually or automatically, while other workpieces are sandblasted at the same time. At the same time, the shot blasted workpiece has no dust and spray in the exit area, and the machine performs the final indexing movement.

The rotating satellite in the shot blasting area ensures uniform movement of the workpiece. Automatic indexing and workpiece rotation provide short cycle time and best shot blasting effect. After the preset shot blasting time expires, the machine indexes one position forward. A new shot blasting cycle begins.

KDT sandblasting machine has shot blasting device arranged vertically or horizontally. The machine can be combined with a robot for loading/unloading and workpiece or processing without any problems.

Features and options
KDT shot blasting machine with horizontal shot blasting wheel

This machine type is used to process gear parts such as shafts and wheels. The 60° wide blast flow ensures that a large number of satellites with workpieces are covered in the shot blasting area. A version with 24 satellites is often used. Due to the large coverage area, short indexing time (no downtime) and uniform shot blasting results can be achieved at low cost.
